Straight Tip Venous Cannula (KX0201)

Changzhou Kangxin Medical Instruments Co., Ltd.
  • Type：Catheter
  • Material：Plastic
  • Ethylene Oxide Sterilization：Ethylene Oxide Sterilization
  • Quality Guarantee Period：Two Years
  • Group：Adults and Children
  • Logo Printing：With Logo Printing

Base Info

  • Model NO.：KX0201
  • Size：10fr-40fr
  • Transport Package：Single Pouch
  • Specification：CE, ISO 13485, ISO 9001 GMP
  • Trademark：Qunxing
  • Origin：China
  • HS Code：9018390000
  • Production Capacity：2000PCS,Week

Description

Basic Info.

Model NO. KX0201 Size 10fr-40fr Transport Package Single Pouch Specification CE, ISO 13485, ISO 9001 GMP Trademark Qunxing Origin China HS Code 9018390000 Production Capacity 2000PCS/Week

Product Description

Straight Tip Venous Cannula (KX0201)Application: In cardiac operation under direct vision, it can be inserted into the vein for blood flow in extracorporeal circulation.

Features:
1. Flexible, kink resistant wirewound body;
2. Thin wall PVC construction;
3. Tapered, multi-port bullet tip for easy insertion and optimum flow rates;
4. Single stage;
5. Straight tip

Model No.: KX0201
Sizes: 12FR 14FR 16FR 18FR 20FR
22FR 24FR 26FR 28FR 30FR
32FR 34FR 36FR 38FR 20FR
MODEL NO.SPECIFICATION  OUTER DIAMETER (MM)CONNECTION SITE
  KX0201-12  12FR  4.0  1/4' '
  KX0201-14  14FR  4.7  1/4' '
  KX0201-16  16FR  5.3  1/4' '
  KX0201-18  18FR  6.0  1/4' ' -3/8' '
  KX0201-20  20FR  6.7  3/8' '
  KX0201-22  22FR  7.3  3/8' '
  KX0201-24  24FR  8.0  3/8' '
  KX0201-26  26FR  8.7  3/8' '
  KX0201-28  28FR  9.3  3/8' '
  KX0201-30  30FR  10.0  3/8' '
  KX0201-32  32FR  10.7  3/8' '
  KX0201-34  34FR  11.3  3/8' '
  KX0201-36  36FR  12.0  1/2' '
  KX0201-38  38FR  12.7  1/2' '
  KX0201-40  40FR  13.3  1/2' '
